Product Description: HVOF Coating Hydraulic Cylinder Rod

Our HVOF coating hydraulic cylinder rods are engineered for extreme durability and reliability in the most demanding industrial environments. Using advanced High Velocity Oxygen Fuel (HVOF) thermal spray technology, we apply a premium tungsten carbide-cobalt-chromium (WC-CoCr) coating that delivers outstanding wear resistance, superior corrosion protection, and significantly longer service life compared to conventional hard chrome plating.

Also commonly referred to as HVOF coating piston rods, these components feature a dense, well-bonded coating layer that ensures excellent performance under heavy loads and harsh conditions. By eliminating the use of toxic hexavalent chromium, our HVOF process also provides an environmentally friendly alternative to traditional plating methods.

How the HVOF Process Works

In the HVOF process, fuel is burned with oxygen to create a high-velocity gas stream. Tungsten carbide, cobalt, and chromium powder particles are injected into this stream, becoming semi-molten and propelled at supersonic speeds toward the rod surface. This creates a dense, low-porosity coating with exceptional adhesion and mechanical properties — far superior to electroplated chrome or other conventional coatings.

---

Technical Specifications

• Base Material: Carbon Steel, Alloy Steel, Stainless Steel

• Coating Type: WC-10Co-4Cr

• Coating Thickness: 0.003″ (0.076 mm), 0.005″ (0.127 mm), 0.01″ (0.254 mm), 0.02″ (0.508 mm), and custom thicknesses

• Hardness: 1,050–1,250 HV

• Bond Strength: >80 MPa (>12,000 PSI)

• Young’s Modulus: 300 GPa

• Porosity: <0.8%

• Surface Roughness: Ra 3.5–4.5 μm (as-sprayed)

• Deposition Efficiency: 40–55%

• Corrosion Resistance: Excellent

• Available Diameters: 20 mm to 200 mm (custom sizes available)

• Available Lengths: Up to 12 meters

---

Key Features and Benefits of Younglee’s HVOF Coating Hydraulic Cylinder Rods

• Exceptional Wear Resistance: Superior resistance to sliding wear, abrasion, cavitation, and erosion

• Outstanding Corrosion Protection: Performs significantly better than chrome plating in corrosive environments

• High Bond Strength: Excellent adhesion to the substrate for long-lasting performance

• Low Porosity: Near pore-free density prevents penetration of corrosive agents

• Eco-Friendly Process: Free from hexavalent chromium and other harmful substances

• Extended Service Life: Proven to last 5+ years in environments where chrome plating lasted only 6 months

• Reduced Maintenance: Longer service intervals and less downtime

• Improved Seal Life: Optimized surface finish extends seal performance

• Chemical Resistance: Excellent performance in acidic, alkaline, and chloride-rich environments

---

Applications of HVOF Coating Hydraulic Cylinder Rods

Our HVOF-coated hydraulic cylinder rods are ideal for equipment operating in harsh and high-demand environments, such as:

• Marine and Offshore: Deck machinery, cranes, winches, and ROV systems

• Oil and Gas: Drilling equipment, refinery dock cranes, production systems

• Mining and Construction: Hydraulic excavators, loaders, and heavy-duty machinery

• Steel Industry: Continuous casting machines and hydraulic systems

• Chemical Processing: Pumps, valves, and corrosive process equipment

• Pulp and Paper: Hydraulic systems in paper mills

• Power Generation: Hydraulic systems in turbines and power plants

---

Younglee Metal Products Co., Ltd. is a trusted manufacturer of HVOF coating hydraulic cylinder rods and HVOF coating piston rods, offering custom solutions for clients worldwide. Contact us today to learn how our advanced coating technology can extend the lifespan and reliability of your hydraulic equipment.
